Powerlab Data Acquisition System include Teaching Software ADINSTRUMENT PowerLab 26T

Features :

Easy to use

• Simple to set up, connects directly to Windows or Mac via USB

• Streamlined integration with analysis software Reliable

• Built to last with 5 year warranty

• Robust and portable

• Fast processor for real-time data acquisition without data loss

• High speed sampling (up to 200kHz per channel) of virtually any analog signal

• 16-bit resolution on all gain ranges for high resolution on even the smallest of signals

• Each channel has individual filters and noise reduction circuitry for minimal channel crosstalk and signal noise Flexible

• Detects a broad range of signals simultaneously, at adjustable sampling frequencies

• Compatible with a wide range of instruments, signal conditioners and transducers

• Independent simulator outputs

• DIN connectors for precalibrated transducers and low-cost amplifiers

• Digital inputs and outputs for external instrument control and triggering

• Adaptable to meet differing research applications

Data communication : USB 2.0

Analog input channels : 4

Single ended inputs : 4

Differential inputs : 4

Input voltage range : ± 20 mV to ± 10 V

Data Resolution : 16 bit

Min sampling rate : 1 S/10 min

Max sampling rate : 100 kS/s

Input crosstalk : > 90 dB

Frequency response : - 3 dB (37 kHz, 10 V)

CMRR : >95 dB @100 Hz, 20-100 mV

Input impedance : 1 MΩ @ 150 pF

Output amplifier : yes

Output channels : 1

Output resolution : 16 bit

Output voltage ranges : ± 200 mV to ± 10 V

Isolated stimulator current range : 0-20mA

Digital output channels : 8

Digital input channels : 8

Built-in bio-amplifier : yes

Safety rating : IEC60601-1

Bio-amplifier channels : 2

Amplification range : ± 200 µV to ± 20 mV

Bio-amplifier CMRR : 110 dB

Isolated stimulator : yes

Pulse duration : 50 – 200 µs

Pulse rate : Software selectable

Include Software : LabStation (Teaching Software)

Fungsi : Sistem perangkat keras yang berfungsi sebagai media transfer informasi data analog dalam proses penelitian dan pengembangan pendidikan
